What Is a Dieline?

Dieline is similar to a template that gives the printer know-how of the exact dimensions and packaging size we want for our business. Its role is pivotal in the printing industry because it ensures that the final layout of the packaging box is perfect from every aspect. The dieline is a diagram with all the cuts and folding points highlighted so that it helps in the design process and generates a carbon copy of the packaging that’s our business requirement.

This terminology is strictly technical, and only the packaging experts or the businesses who require product packaging fully understand it. But you can’t downplay its importance in custom packaging as it plays its part in ensuring accuracy and precision in the packaging box’s measurements. The designers and manufacturers take the help of dieline as a reference to meet the expectations of their clients. The dieline pinpoints all the cuts and perforations in a flattened form of packaging.

The value of a dieline becomes important if you want to replicate an existing packaging box and, like the printing enterprise, follow it as a blueprint. In some cases, the businesses send a packaging box to the printing company and ask it to pursue its dielines. The experts review the box and assess all the folding cuts, glue tabs, and lines to ensure the result is exactly as envisaged.

Visit Thelegacyprinting Shop or request a price and tell us more about your project if you’re interested in Custom packaging!

Significance Of Dielines

The dielines help you determine how you want your final packaging to look. The die-cutting process is complex, and it can be carried out with great precision if all the cuts are properly defined. It offers help in determining the following key packaging components:

  • Dimensions
  • Scaling
  • Placement of logos or text
  • Cutlines
  • Fold lines
  • Bleed lines
  • Glue tabs
  • Creases

The designers consider all of these elements, and by following the dieline, they can manufacture the best physical design for packaging. Dielines are often used to create any packaging, including food, beverage, brochure packaging, and any other product that requires specialized packaging.


Knowing how your package will appear before the die-cutting process offers you peace of mind that the positioning, colors, dimensions, and patterns are all in the appropriate location. Furthermore, because the flat laying blueprint offers an overall picture of your design, checking your dieline helps you notice any design, text, or dimensions problems at the early stage.

Who Can Create the Dieline?

Usually, the creation of dieline is the job of expert packaging designers. They are fully aware of the minute details and dive deep to craft the best design for the encasing. We can also create the dielines with the help of a printer or specialized die cutters. It also presents a chance to gather feedback from other stakeholders such as the marketing department, graphic designers, and top management. Their input at this prototype phase helps in saving valuable time and expenses.

Providing package designers with current packaging designs or boxes similar to what you have in mind is the greatest approach to guarantee timelines are accurate to your custom packaging vision. This provides a solid beginning idea for the designer, which you can adjust until the final box is agreed upon.

dieline thelegacyprinting 1916118730

A manufacturer will likely provide the designer with a complete dieline that includes bleed requirements and remarks. The Legacy Printing is the go-to platform for getting custom labels or stickers printed on different objects at an economical price. It also offers free custom design support and a free shipping option across the USA.

How To Create Die Cut Lines in Illustrator?

Setting up dielines on Adobe Illustrator requires a user to follow some basic steps in the right sequence. Following are some of the key steps for creating a dieline on Illustrator:

  1. The first thing that needs to be done is to create an artboard to design the desired object. Select the appropriate resolution and color system like CMYK.
  2. After laying out the artboard, make sure that you save the file, so you don’t lose your valuable work and effort because of any problem.
  3. Use visuals according to the set standards in the industry. Cutlines are identified by a solid red color and are 0.25 or 0.50 points thick. We can locate the folds through dotted red lines. You can also draw the lines with the help of the Pen tool in Illustrator.
  4. Once you are done with the dieline making process, press the lock option on the layer to keep your work secure.
  5. When you complete work for the first round of designs by considering all the basic elements such as cuts, folds, and glue tabs, now you need to take a print to build a prototype.
  6. It’s the right time to identify if the measurements are slightly off or what you can do to ensure maximum precision in design.
  7. Now you can take the print and assemble it to check whether it fulfills the dieline requirements mentioned by the client.

deieline illustrator thelegacyprinting

Considering some important factors is crucial while creating the dielines. We need to make the dielines as vector art because it helps the computer understand the mathematically drawn lines easily. Using Adobe Illustrator is also important because it helps save a lot of precious time and money to overcome all the design loopholes.

How To Make a Box Template in Photoshop?

The ability to make a packaging box template on Adobe Photoshop can give the designers an edge in the market, and they can use this skill to grow further. The right template can help the printing enterprise tell clients what the actual design would look like. Businesses looking for product encasing can see these templates to develop an overview of the type they are looking for.

We can follow the below-mentioned steps to create a box template on photoshop:

  1. Place the jpg files in Adobe Photoshop. Add three different jpg files together, including the front, back, and side view of the packaging box. We can perform this action by going tothe File > Place
  2. Select the layers of the jpg files and rasterize them so you can edit them with ease. Go to Layers > Rasterize > Layers. Now you can change the sides of the box by selecting the Free Transform tool and dragging different sides to alter the shape. Using the tool, you can drag the edges to modify the packaging box’s look.
  3. Trim the back corner and use the Lasso tool to make it look more realistic. Use the rectangle tool to create a shadow effect.
  4. Create a duplicated layer and give some reflection to the packaging box. Place the duplicated layers over each other, click the Layer Masks button and then Gradient option and drag it over the edges to create a reflection effect.

By following these basic steps, you can learn how to make a product box in photoshop and use them as templates to offer more value to the users.

Uses Of Print & Trim Boxes

The thick stock paper makes up the print & trim boxes, and these are the flat sheets that you can customize according to the business requirements. The packaging boxes can be printed and coated with unique designs and are available in a wide range of shapes and sizes. We can use these packaging boxes for custom printing and packaging where the businesses want their input in the box design and form. For example, we can use the trim boxes for gift purposes, apparel packaging, health and beauty boxes, and packing electronics.

Visit Thelegacyprinting Shop or request a price and tell us more about your project if you’re interested in Custom packaging!

The great thing about the whole customization process is that there are no restrictions. You can get the packaging in any shape or form and print any labels, text, or logo to create a more personalized bond with the target audience. The appropriate placement of the logo and the brand theme makes it convenient for the users to pick your product on the store shelf over other top competitors.

Want Any Help Regarding the Dieline?

Now that you’ve learned what are dielines, you can use them as a template for the physical design of the packaging. So, we are here to help you guide on using the dieline and how it can ease the whole printing process by pointing out the cuts and areas that need trimming.

The Legacy Printing is a renowned custom packaging and printing firm in the USA with years of experience and a skilled workforce. There’s no setup cost involved, and the die-making is free of charge.

The design team is highly professional and works with great precision and accuracy to craft the best packaging box layout for you. We are adept at producing die-cut boxes in all shapes and sizes so you can make headway in the industry and make the packed items more enthralling and appealing for potential customers.
